750mm 6

Basic Info.

Model NO.	750mm 6-hi reversible type
Rolling Model	Reversible and Continuous Type
Stand Type	Single Type and Tandem Type
Independent Intellectual Property Right	Yes
Advantage	All Around Pre-Sale and After Sale Service
Roller Type	4/6/8/12/20 Roller Type
Width	From 350mm to 1450mm
Thickness of Finished Products	0.01mm to 3.0mm
Application	Plain Carbon Steel, Stainless Steel, Alloy Steel
Transport Package	Plywood Box or Films or as Required
Specification	it depends on the specificiation
Trademark	Moran
Origin	China
HS Code	845522100
Production Capacity	5 Sets

Product Description

General Information of 750mm 6-hi reversible-type board material cold rolling Mill
This quotation for 750mm 6-hi reversible-type board material cold rolling unit project is made for the equipment project of cold rolling steel board material production line.Technical referencing data
Standard of coming material

Material quality	pickled hot rolled coil Q195, Q235, SPCC, SPCD, SPCE, SS400, S35 C
Machine function	σ S=360Mpa(before rolling)
Thickness	2.0-3.0mm
Width	650-750mm
Rolling diameter(interior/exterior)	Φ508/(1800-900)mm
The maximum rolling weight	12t

Standard of finished products

Thickness	0.3-2.0mm
Width	650-750mm
Rolling diameter(interior/exterior)	Φ500/(1800-900)mm
The maximum rolling weight	12t

Technical referencing data
Standard of coming material

Material quality	pickled hot rolled coil Q195, Q235, SPCC, SPCD, SPCE, SS400, S35 C
Machine function	σ S=360Mpa(before rolling)
Thickness	2.0-3.0mm
Width	650-750mm
Rolling diameter(interior/exterior)	Φ508/(1800-900)mm
The maximum rolling weight	12t

Standard of finished products

Thickness	0.3-2.0mm
Width	650-750mm
Rolling diameter(interior/exterior)	Φ500/(1800-900)mm
The maximum rolling weight	12t

Product precision
Larger than 0.5 deviation of lengthways thickness ≤2%h,less than 0.5 common difference of lengthways thickness ±0.1
Precision of board shape: the maximum allowing value of inequality of product
Main technical referencing data
* Rolling machine standard: Φ800/300/250*850mm
* The maximum milling pressure: 8000KN
* The maximum milling nonmetal: 45KN.m
* Through-tape speed: 18m/min
* Rolling speed: maximum 900m/min
* Uncoiler tension: 20-3KN
* Rolling tension: 100-10KN
* The maximum rolling speed: 960 m/min
* Unilateral bending roll force of work roll(positive/negative): 350/210KN
* Diameter of work roll: Φ230-250 mm
* Roll body length of work roll: 850 mm
* Unilateral bending roll force of work roll(positive/negative): 150/6KN
* Unilateral bending roll force of middle roll: 150KN
* Landscape orientation moving force of middle roll: 250/150KN
* Diameter of middle roll: Φ280-300 mm
*The roll body length of middle roll:825mm
* Traverse amount of middle roll: 150 mm
* Diameter of support roll:Φ750-800 mm
*The roll body length of support roll: 760 mm
*The maximum open degree of work roll: 15 mm
* Floating amount of axial direction of reel of uncoiler: 75 mm
* Standard elevation of rolling line: +1100 mm
* Adjusting procedure of standard elevation of rolling line: 95 mm
* Lubricating flow rate of technical art: 4000 l/min
*Working pressure of hydraulic pressure system:
Balance,bending roll,traverse:12-15Mpa
Usual hydraulic pressure deliver and rotation:10-12Mpa
* Total capacity of electric appliance installation of machinery unit mechanical equipment:
Main Configuration

1	Main electrical machinery	DC 1000KW 660V	Set	2
2	Electrical machinery of coiler	DC 750KW 660V	Set	4
3	Electrical machinery of uncoiler	DC 160KW 440V	Set	1

Direct current: 5160KW
Alternating current:300KW
* The exterior shape dimension of mechanical equipment of machine unit (length *width *standard height) 16*18*8m
For more information, please feel free to contact us.
Our advantage:
1) Customized Production
2) High cost-effective product
3). All-around pre-sales & after-sales services4) Independent intellectual property rights
